Our Power Sourcing Equipment (PSE) solutions implement the latest IEEE 802.3bt standard to power multi-Ethernet port switches, gateways, and routers.

Si3474 powers up to four 802.3bt 4-pair Ethernet ports with 90 W per port and supports thermally efficient 200mΩ current sense resistors. It is fully backwards compatible with 30 W and 15 W devices. The new Si3472 powers up to four 802.3bt 2-pair Ethernet ports with up to 45 W per port. The new Si3473 powers up to eight 802.3bt 2-pair Ethernet ports with up to 45 W per port.  All Skyworks multi-port PSE devices support autonomous or hosted operation, automatically detecting valid Powered Devices (PDs) and cutting off port power when connected PDs are removed. In addition, each PSE device provides a full featured I²C register interface for advanced power management and control.
