Si462x Automotive Digital Data Receivers

The Si462x devices enable HD Radio™/DAB/DAB+ services reception and provide significant advances in size, power consumption, and performance.  The high level of integration and complete system production test simplifies design-in, increases system quality, and improves reliability and manufacturability. With a fully integrated decoder for the European Radio Data System (RDS) and the North American Radio Broadcast Data System (RDBS), functions include all required symbol decoding, block synchronization, error detection, and error correction. The Si462x provides an integrated clock oscillator or accepts a reference clock and supports a selectable control interface (SPI or I²C).
